China rohs2 Introduction to the latest testing standards
Date：2021-12-30 15:21:00Views：1555
In order to adapt to the restriction requirements of new types of hazardous substances and the development of new detection technology in the electronic and electrical industry, and promote rohs2 0 detection technology development, while ensuring rohs2 0 the test results are consistent with the international ones, and China's rohs2 0 the working group initiated the revision of GB / T 26125-2011 and equivalent transformation of a series of standards revised and issued by IEC 62321 to support the implementation of the administrative measures for the restriction of the use of hazardous substances in electrical and electronic products and China rohs2 0 implementation of conformity assessment.
On October 11, 2021, the State Administration of market supervision (State Standardization Administration Committee) approved and issued four GB / t39560 series standards for the determination of certain substances in electronic and electrical products. This release is another release after the five GB / t39560 series standards issued on December 14, 2020. So far, China's RoHS 2.0 supporting testing standards have been released.
1 |
GB/T 39560.1-2020 |
Determination of certain substances in electronic and electrical products Part 1: introduction and overview Equivalent to IEC 62321 standard: IEC 62321-1:2013 |
|
Published on:2020-12-14 |
|
Implementation time:2021-07-01 |
|
2 |
GB/T 39560.2-2020 |
Determination of certain substances in electronic and electrical products Part 2: disassembly, disassembly and mechanical sample preparation Equivalent to IEC 62321 standard: IEC 62321-2:2013 |
|
Published on:2020-12-14 |
|
Implementation time:2021-07-01 |
|
3 |
GB/T 39560.301-2020 |
Determination of certain substances in electronic and electrical products Part 3-1: screening of lead, mercury, cadmium, total chromium and Total Bromine by X-ray fluorescence spectrometry Equivalent to IEC 62321 standard: IEC 62321-3-1:2013 |
|
Published on:2020-12-14 |
|
Implementation time:2021-07-01 |
|
4 |
GB/T 39560.4-2021 |
Determination of certain substances in electronic and electrical products Part 4: Determination of mercury in polymers, metals and electronic components by CV-AAS, CV-AFS, ICP-OES and ICP-MS Equivalent to IEC 62321 standard: IEC 62321-4:2013 |
|
Published on:2021-10-11 |
|
Implementation time:2022-05-01 |
|
5 |
GB/T 39560.5-2021 |
Determination of certain substances in electronic and electrical products Part 5: Determination of cadmium, lead and chromium in polymers and electronic components and cadmium and lead in metals by AAS, AFS, ICP-OES and ICP-MS Equivalent to IEC 62321 standard: IEC 62321-5:2013 |
|
Published on:2021-10-11 |
|
Implementation time:2022-05-01 |
|
6 |
GB/T 39560.6-2020 |
Determination of certain substances in electronic and electrical products Part 6: Determination of polybrominated biphenyls and polybrominated diphenyl ethers in polymers by gas chromatography-mass spectrometry (GC-MS) Equivalent to IEC 62321 standard: IEC 62321-6:2015 |
|
Published on:2020-12-14 |
|
Implementation time:2021-07-01 |
|
| 7-1 | GB/T 39560.701-2020 |
Determination of certain substances in electronic and electrical products Part 7-1: Determination of hexavalent chromium [Cr (VI)] in colorless and non-ferrous anticorrosive coatings on metals by hexavalent chromium colorimetry Equivalent to IEC 62321 standard: IEC 62321-7-1:2015 |
|
Published on:2020-12-14 |
|
Implementation time:2021-07-01 |
|
| 7-2 | GB/T 39560.702-2021 |
Determination of certain substances in electronic and electrical products Part 7-2: Determination of hexavalent chromium [Cr (VI)] in polymers and electronic components by hexavalent chromium colorimetry Equivalent to IEC 62321 standard: IEC 62321-7-2:2017 |
|
Published on:2021-10-11 |
|
Implementation time:2022-05-01 |
|
8 |
GB/T 39560.8-2021 |
Determination of certain substances in electronic and electrical products Part 8: Determination of phthalates in polymers by gas chromatography-mass spectrometry (GC-MS) and gas chromatography-mass spectrometry with pyrolysis / thermal desorption (py / td-gc-ms) Equivalent to IEC 62321 standard: IEC 62321-8:2017 |
|
Published on:2021-10-11 |
|
Implementation time:2022-05-01 |
China rohs2 0 test standard is equivalent to IEC 62321 series standards to realize China rohs2 0 testing and international rohs2 0 detect docking and mutual recognition, and realize China rohs2 0 standards and relevant control requirements of EU and other regions or countries, and the consistency of testing methods.
After the implementation of GB / t39560 series standards, it will replace the current Chinese ROHS testing standard GB / t26125-2011 and add Chinese rohs2 0 the standard method for the detection of new substances improves the existing rohs2 All detection contents of the 0 instruction are overwritten.
About rohs2 0：
Currently rohs2 The control standards in directive 0 include elements (valence substances) and organic compounds;
Limit of restricted substances (mass fraction%)
Lead (PB) 0.1%
Mercury (Hg) 0.1%
Cadmium (CD) 0.01%
Hexavalent chromium (CR VI) 0.1%
Polybrominated biphenyls (PBB) 0.1%
Polybrominated diphenyl ether (PBDE) 0.1%
Di (2-ethylhexyl) phthalate (DEHP) 0.1%
Toluene butyl phthalate (BBP) 0.1%
Dibutyl phthalate (DBP) 0.1%
Diisobutyl phthalate (DiBP) 0.1%
